Redding 700 Ultramag Single Stage Press

The Redding Model 700 Ultramag Single Stage Press features a huge frame opening and very long useable ram stroke, making it ideal for loading oversize cartridges such as the old Sharps “Buffalo Cartridges” and British Nitro Express rounds. Its unique long link compound leverage system has more mechanical advantage over a greater distance than any other reloading press on the market. Includes primer catcher and primer arm for large and small primers. Dies and shellholder sold separately.

Technical Information

Press Type: Single Stage
Frame Material: Cast Iron and Steel
Frame Design: C-Frame
Frame Offset: 0
Frame Opening Size: 4-3/4″
Handle Location: Bottom right hand
Die Size Accepted: Standard 7/8″-14 threaded die with adapter inserted, with adapter removed 1-1/4″-12 threaded dies, with optional adapter 1″-14 threaded dies (sold separately)
Die Bushing Accepted: No
Die Bushing Brand Used: N/A
Spent Primer Collection System: Built in
Ram Stroke: 4-1/8″
Ram Diameter:
Priming Feature: “Smart” primer arm and large and small primer cups included
Number of Mounting Holes: 4
Mounting Hardware Included: No
Additional Features: Compound Leverage
Warranty: Lifetime warranty against defects in materials and workmanship
